| Inlet | 1″F swivel (other connections available upon request) |
| DN (mm) | 300-600 |
| Weight (kg) | 22 |
| Skid length (mm) | 450 |
| Total length of the centralizer w/joint (mm) | 500 |
| Maximum Pressure (bar) | 250 |
Centralizer DN 300-600
Centralizer for DN300-600 pipes, with 4 skids fitted with steel wheels, that allow the guide to easily slide along the pipe. The skids give stability to the centralizer, particularly strained when used with nozzles with chains.
Through a mechanical device it is possible to adapt the position of the guide inside the pipe, to optimize the efficiency of the nozzle.
In order to enable the connection with the flexible hose a swivel jont has been installed.
It is a must for nozzles with chains (Maniago, Friuli, Catena), and recommended for slow rotation nozzles (Warthog).
Technical Specifications
Items
| Part No. | Description | |
|---|---|---|
| 5025.03 | EXTENDABLE CENTRALIZER 1″ M-F 300 – 600MM IN STEPS |
